Extract with json path

Description

The Extract With JSON Path activity extracts data from JSON-encoded columns using a user-defined JSONPath expression. This is useful for parsing nested JSON objects and retrieving specific elements.

Use case:
When a column contains raw JSON (e.g., {"user": {"name": "Alice"}}), this activity allows you to extract specific values (e.g., .user.name) and move them to a separate column.

---

Input

Type	Description
Data	Dataset containing JSON column(s)

---

Output

Type	Description
Transformed Data	Data with a new column containing extracted values from JSON

---

Configuration Fields

Field Name	Required	Description
Column Name	Yes	The column that contains the JSON string
Output Column	Yes	Name of the new column that will hold the extracted result
JSON Path	Yes	JSONPath expression to select the value from the JSON (e.g., $.user.name)
Include Original	No	If enabled, retains all original columns; otherwise, shows only the result

---

Sample Input

ID	Data
1	{“user”: {“name”: “Alice”, “age”: 25}}
2	{“user”: {“name”: “Bob”, “age”: 30}}
3	{“user”: {“name”: “Charlie”, “age”: 28}}

---

Sample Configuration

Field	Value
Column Name	Data
Output Column	ExtractedValue
JSON Path	$.user.name
Include Original	No

---

Sample Output

ExtractedValue
Alice
Bob
Charlie

---

You can extract nested elements using dot notation, arrays with [index], and even filter expressions depending on your use case.
For example: $.users[0].name or $..name
